S.NO. |
DESCRIPTION |
MEASURES |
1. |
LENGTH OVER COUPLING FACES |
10713 mm. |
2. |
LENGTH OVER HEAD STOCKS |
9784 mm. |
3. |
BOGIE CENTRES |
6524 mm. |
4. |
LENGTH OVER END TOP COPING
|
10092 mm. |
5. |
WIDTH OVERALL
|
3143 mm.
|
6. |
JOURNAL CENTRES |
2260 mm. |
7. |
HEIGHT OVERALL |
3581 mm. |
8. |
HEIGHT OF CENTRE BUFFER COUPLER FROM RAIL LEVEL
|
1105 mm.
|
9. |
ESTIMATED TARE WEIGHT
|
19.85 t. |
10. |
PAY LOAD |
71.0 t. |
11. |
GROSS WEIGHT |
100.0 t. |
12. |
AXLE LOAD
|
25.0 t.
|
14. |
GROSS WEIGHT PER METRE RUN OVER COUPLING FACES (T.L.D) |
9.334 t/m.
|
15. |
C.G. FROM RAIL LINE (EMPTY)
|
1.03 m.
|
16. |
C.G. FROM RAIL LINE (LOADED) |
2.20 m.
|
